Double Roller Shredder Wood Crusher Machine With Big Feeder Opening

I'm Online Chat Now

Double Roller Shredder Wood Crusher Machine With Big Feeder Opening

China Double Roller Shredder Wood Crusher Machine With Big Feeder Opening supplier
Double Roller Shredder Wood Crusher Machine With Big Feeder Opening supplier Double Roller Shredder Wood Crusher Machine With Big Feeder Opening supplier Double Roller Shredder Wood Crusher Machine With Big Feeder Opening supplier Double Roller Shredder Wood Crusher Machine With Big Feeder Opening supplier

Large Image :  Double Roller Shredder Wood Crusher Machine With Big Feeder Opening

Product Details:

Place of Origin: CHINA
Brand Name: WHOLLY
Certification: CE, ISO
Model Number: Shredder 500, shredder 600

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD5000-USD7000 per set
Packaging Details: standard export wooden pallet
Delivery Time: 15-20 days after receive deposit
Payment Terms: L/C, , T/T, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Power: 7.5KW * 2 Gearbox: 350 * 2 / 400 * 2
Materials Of The Hob Cutters: 9CrSi (Optional) Diameter Of The Hob Cutters: φ220 Mm
Thickness Of Hob Cutters: 10mm / 20mm Quantity Of Hob Cutters: 16 Pcs / 24 Pcs / 48 Pcs
Rotate Speed Of The Hob Cutters: 18-25 RPM Size Of Feeding Materials: ≤400*400 Mm
Size Of Output Broken Pieces: ≤20mm Capacity Of The Machine: ≤1 T/H

Double roller shredder 500 model and 600 model



Application of the shredder

Double-roller shredder is widely applied in construction waste, industrial waste, domestic waste, municipal waste, garden waste, medical waste, food waste, and biomass materials waste crushing and recycling fields. For example, you can use double-roller shredder to crush scrap steel, scrap iron, waste rubber, waste plastic, scrap wood pallet, cloth, and so many big materials into small broken piece.



Working principle

Double-roller shredder use dual-motor to drive dual-gearbox, turn high rotate speed of the electric motors into low rotate speed of cutter rollers by gearboxes, then cutting, squeezing, and tearing big materials, shred them into small broken pieces.

The rotate speed of the cutter roller is nearly 10-25RPM. Low rotate speed with high torque force. And the materials of cutters are high quality alloy steel with good abrasion resistance.



The performance characteristics

1. The rotate cutters are made by high quality alloy tool steel with very high tear strength, high abrasion resistance. The cutters are scalable and adjustable. And they can be sharpened repeatedly when they are blunt, long service time.

2. The rotate speed of the cutter is very low, the machine with high torque force, heavy energy with high crushing capacity.

3. Composite structure frame made of special thick plate precision machining, it is very strong and durable, resistant high torque.



Technical parameter

Model No. 500 600
Power 7.5KW * 2
Gearbox type 350 * 2 400 * 2
Materials of the hob cutters 9CrSi (Optional)
Diameter of the hob cutters φ220 mm
Thickness of hob cutters 20 mm 10 mm 20 mm
Quantity of hob cutters 16 pcs 48 pcs 24 pcs
Rotate speed of the hob cutters 18-25 RPM
Size of feeding materials ≤400*400 mm ≤500*500 mm
Size of output broken pieces ≤20mm ≤10mm ≤20mm
Capacity of the machine ≤1 T/H
Dimension of the machine 2.0*0.8*1.8 m 2.4*0.87*2.2 m
Weight of the machine 2.3T 3T
