|Output:||3-4T/H||Diameter Of Ring Die:||1000mm|
|Gearbox:||Industrial Gearbox, High Precise Gears||Lubrication:||Automatic Lubrication System|
|Color:||According To Clients' Requirements||Package:||Very Durable Iron Case|
wood pellet making machine,
wood pellet mill
Advantage of biomass pellet making machine:
1. Gearbox: driving with high-precision gears, anto-matic lubricant pump system to keep the gearbox working stability.
The warranty of the gearbox are 5 years.
2. Electrical motor: vertical design for the motor, mounting hole with output as the center, equidistant distribution around,
more powerful and stability of machine working.
3. Blower system: Located in one side of work bin, free control the working time, the main function is dedusting
and discharge steam.
4. Working parts: ring-die and roller materials are alloy steel, after heat treatment, the hardness can be more than 52.
The serivice time can be 1800~2000 hours.
The roller working manner is from inside to outside press, centrifugal force and extrusion pressure together, produced
more capacity. And the special design is 4-rollers working, to increase press rate.
Ring-die is vertical double-deck structure. It means you can use one mould with different hole size.
Product features of biomass pellet making machine:
1. FD series Design of the ring-die wood pellet machine: double vertical. The electrical motor is vertical, the ring-die is vertical.
2. They are professional machines for wood, straw, rotton stalk, rice husk, peanut shell, bamboo, empty fruit branch,
palm fiber, ect.
3. Warranty time: the electrica motor is one year, the machine is 3 year.
4. After-sales service: Life time after-sales serives.
Technical parameters of biomass pellet making machine:
||Model No.||Ring die pellet making machine FD1000|
|Output pellets diameter||6~12mm|
||Power of main motor||200KW|
|Model No. of main motor||315L-4|
|Voltage of main motor||380V / 3 phase / 50hz|
|Packing size||2650*1450*2100 mm|
||Lubricate bearings on the main shaft||0.37KW automatic lubricant pump|
|Lubricate bearings on the pressing roller||0.37KW automatic machine|
||The diameter of the ring-die||1000mm|
|Thickness of the ring-die||65mm|
|The material of the ring-die||Alloy steel, heat treatment, hardness more than 52HRC.|
|Dust collecting system||Power of the dust-collector||1.1KW / 3 phase / 50hz|
|Electric control cabinet
|Gearbox||Standard industrial gear box, high precise gears|
